Key Features
200cc single-cylinder four-stroke engine
Automatic CVT transmission
Forward and reverse
Electric start with pull-start backup
Adjustable driver's seat
Two-seat configuration with seat belts
LED headlights
Rear hydraulic disc brake
6 litre fuel tank
Up to 45 km/h
130 kg maximum combined load
Technical Specifications
ENGINE
| EPA Certificated | Yes |
| Engine | 4-stroke, single cylinder, air cooled |
| Displacement | 200cc |
| Max HP | 6.3 HP @ 3600rpm |
| Max Torque | 13 N.m @ 2500rpm |
| Bore x Stroke | 66mm x 53.5mm |
| Max Speed | 45 km/h |
| Climbing Ability | 12 degrees |
| Ignition | C.D.I |
| Starting System | Electric / pull start backup |
| Battery | 12V 9Ah |
| Carburettor Brand | JF (RX) |
| Engine Oil | SG15W-40 |
GENERAL INFORMATION
| Clutch | Automatic CVT |
| Driveline / Driving Wheel | Chain / Dual wheel drive |
| Suspension Front / Rear | Double A-arm / Swing-arm (Double Oil Damped Shock) |
| Brakes Front / Rear | No / Hydraulic brake, Disc |
| Tyres Front | 16 x 6-8 |
| Tyres Rear | 16 x 7-8 |
| Fuel Capacity | 6 L |
| Weight N.W. | 150 Kg |
| Max Load | 130 Kg |
